Hydroxyethyl cellulose(HEC)

Hydroxyethyl Cellulose is a series of non-ionic soluble cellulose ether, which can be dissolved in hot or cold water, and has the characteristics of thickening, suspending, adhesives, emulsion, film coating super absorbent polymers protective colloid, which is widely used in paints, cosmetics, oil drilling and other industries.

Grades and applications

Application

Cement Based Renders and Trowelling Compounds
Emulsion Based Systems
3D Concrete Printing
Paints
Ceramics
Polymerisation
Personal Care
Home Care
Oilfield
Others

HEC
EHH	H 10 YG4	H 15 YG4	H 20 P2	H 20 YG4	H 25 YG4	H 200 NP2	H 300 NG4	H 300 P2	H 300 YP2	H 4000 NG4	H 4070 NG4	H 10000 NG4	H 10000 P2	H 15000 YP2	H 30000 YP2	H 30070 NP2	H 100000 YP2	H 100070 NP2	HA 40 YP2	HC 50 NP2	HQ 6000 YG4 Plus	HS 250 YG4	HS 6000 YP2	HS 6002 YP2	HS 15000 YP2	HS 30000 YP2	HS 60000 YP2	HS 100000 YP2	HS 200000 YP2	HX 6000 YG4 Plus	HX 500 T
			•					•																		•
																							•	•	•	•	•
								•																		•
																						•	•		•	•	•	•	•	•	•
		•													•		•
	•	•		•	•				•										•			•				•
		•	•				•			•	•	•	•	•	•	•	•	•			•					•		•
										•		•											•			•	•	•		•
•						•		•												•		•		•		•		•
																	•									•	•

HEC provides excellent thickening efficiency, color development, open time, and superior resistance to biodegradation. It also plays a role in the emulsion, dispersion, stability and water retention. The coating has good rheological properties at different shear rates, and has good workability and leveling performance, good splash and sag resistance.
The major advantages that HEC offers as a coating thickener are:
• Excellent color development and color acceptance
• High thickening efficiency
• Compatibility with a broad range of paint ingredients
• Batch to batch uniformity
• Good brush and roller application
• Anti-sagging properties
• Water soluble

As one of professional Hydroxyethyl cellulose suppliers, Zeicel provides series of high quality HEC products to meet several industries for our customers around the world. Our main HEC products include Z150B, ZHQ100.

Z150B

ITEM	SPECIFICATION	RESULT
Appearance	White or off – white powder , no visible evidence of contamination by foreign matter	Conforms
Identification	Conform	Conforms
PH	6.0 – 8.5	7.9
Viscosity ( Brookfield , 1% , 25o C)	5600 – 7000 cp	6650
Particle Size	Min 92% pass 80 mesh	Conforms
Loss on Drying	Not More Than 6.0%	5.2%
Residue on Ignition	Not More Than 5.0 %	3.1%
Conclusion : conforms with Q/MXHP005 – 2016

ZB100

ITEM	SPECIFICATION	RESULT
Appearance	White or off – white powder , no visible evidence of contamination by foreign matter	Conforms
Identification	Conform	Conforms
PH	6.0 – 8.5	7.8
Viscosity ( Brookfield , 1% , 25o C)	3400 – 5500 cp	5190
Particle Size	Min 92% pass 80 mesh	Conforms
Loss on Drying	Not More Than 5.0%	5.2%
Residue on Ignition	Not More Than 5.0 %	3.3%
Conclusion : conforms with Q/MXHP005 – 2016

ZB100 Plus

Appearance	White or similar to white powder
Moisture (%)	Max. 6.0
Ash content (%)	Max. 5.0
PH	6.0 – 8.5
Bulk density	0.30 – 0.50 g/cm3
Particle Size	Min 92% pass through 80 mesh
Brookfield	3400 – 6000 mpa.s
